SPARK SERIES FLYPACKS SEND SHOCKWAVES
Meet the SPARK Series Flypack, Thunder City Pro’s compact solution for complex, 4K HDR production demands. SPARK Series Flypacks are designed to deliver reliable, high quality live broadcasts while also providing polished content for post-production and social media. Thunder City Pro’s featured SPARK Series Flypack shown below has handled high-profile productions with Jimmy Eat World, Riley Green, T-Pain, KB, the Tampa Bay Rays and more.
SPARK Series Flypacks are available for both rental and purchase. A fully equipped rental system can be deployed immediately, or the package can be adapted to match the unique requirements of a production. For those seeking a permanent solution, SPARK Flypacks can be purchased and developed from the ground up. Each project begins with expert consultation from Thunder City Pro to identify the ideal gear and workflow, and results in a turnkey system engineered for long-term performance.
The rental SPARK Series Flypack featured here is built for 4K HDR workflows, supporting up to 20 camera inputs with multiple ISO record and playback channels. Its camera package includes Sony Pro cinematic cameras, G Master zoom lenses, BMD Micro Studio 4K G2 units, and Panasonic Leica MFT lenses, giving crews the tools to capture every angle with clarity and consistency.
This system enables reliable, cinematic multi-camera coverage, seamless switching, and smooth integration across all aspects of live production. Engineered for efficiency and portability, it delivers the full capabilities of a traditional control room within a compact footprint. With its clean design and proven performance, the SPARK Series Flypack is a dependable solution for productions that require professional results without the expense or size of a full mobile unit.
SPARK SERIES FLYPACK RENTAL SPECIFICATIONS
Highlights
4K HDR Workflow
(11) Cameras w/ Various Lenses
Up to 20 Cameras/Inputs
Wireless Video Systems
Record or Playback Channels (2 with Fill/Key)
VMIX Production System for Streaming/Encoding
Cameras and Support
Sony PXW-FS7 4K Super 35mm Exmor CMOS sensor XDCAM camera with α Mount lens system, 4K/2K RAW and XAVC recording options
Sony E PZ 18–110 mm F4 G OSS APS-C Standard Power Zoom G Lens with Optical SteadyShot
Sony E PZ 18–105 mm F4 G OSS APS-C Standard Power Zoom G Lens with Optical SteadyShot
XDCA-FS7 12-bit RAW Extension Unit for PXW-FS7
Sony FR7 Cinema PTZ with RM-IP500 Controller (optional add-on and multiple available)
DJI Ronin 4D 4-Axis Cinema Camera 6K Combo Kit with DL PZ 17-28mm T3.0 ASPH Lens
Sony FE 24-70mm F2.8 GM II Full-frame Standard Zoom G Master Lens
Sony FE 12-24mm F2.8 GM Full-frame Ultra-wide Zoom G Master Lens
BMD Micro Studio Camera 4K G2
Panasonic Lumix G Series LEICA 9mm F1.7 MFT Lenses
Hollyland Mars 4K Wireless Video Transmission System TX/RX
Middle Things APC Ronin/Micro Cam PTZ Control
NP-F970 Batteries w/ (2) 4 Bay Chargers
BP-U60 Batteries w/ (1) 2 Bay Charger
TCP WiFi Wireless Mini Tally Light Cubes
Video
BMD ATEM 2 M/E Constellation 4K
Streamdeck XL 32 Button Control Surfaces
Streamdeck Studio 32 Button 1RU RCP
Inputs up to 4K@60P (12G-SDI)
(12) Outputs with Embedded Timecode
(2) 4K 16CH Multiviewers on (2) Asus ProArt Color Accurate 4K Monitors
(1) BMD SmartView 4K G3 Ultra HD Broadcast Monitor for PGM QC
Hyperdecks for PGM/ISO Record, as well as Playback with Fill/Key Outputs
BMD HyperDeck Studio HD Pro w/ (4) Samsung EVO 2TB SSDs
BMD HyperDeck Studio HD Plus w/ (4) Lexor V60 SD Cards
Samsung T7 Shields 1TB SSD for BMD RAW Micro Camera ISO Record
VMIX 28 Pro PC with NVIDIA 4070Ti Super FE, 128GB RAM, Intel i9 Processor, 1TB NVMe
BMD Mini Converter 6G-SDI DA
BMD 12G HDMI/SDI Converters Kit
Audio
Behringer WING Compact or WING Rack 48-Channel / 28-Bus Full-Stereo Digital Mixing Console
Optional DigiCo S21/S31 w/ 48 Flexi Input Channels (optional add-on and multiple available)(1) WING-DANTE Expansion Card for 64x64-Channel Audinate Dante AoIP Networking
Mac Mini Intel i7 w/ Waves Ultimate Plugins and Waves SuperRack Performer
JBL 305P MkII Powered 5" Two-Way Studio Monitors
Yamaha Tio1608-D2 16x8 Dante-Equipped I/O Racks
Audio-Technica AT875R Short Shotgun Microphone w/ Windscreens
Intercom
RTS OMS OMNEO Main Station Advanced Digital Partyline Intercom Frame
RTS KP4016 for the Director/TD
(40) OMNEO/Dante Ports
(4) RVON Ports
(4) 4W Analog Ports
(4) 2W Dry Analog Ports
Up to (8) RTS KPs
Hollyland SOLIDCOM M1 1.9GHz DECT Full Duplex Wireless Intercom System with (8) Beltpacks/Double Muff Headsets
Grip/Rigging
Manfrotto/SmallRig Magic Arm Kit
Floor Mic Stands
C-Stands w/ Extension Arm Matte Black
Magnet 1/4-20 Swivel Head Mounts
Additional Equipment
SPARK Flypack Cover/Lid Table for Audio
Mikrotik RB5009 Network Router
Mikrotik CRS328-24P 24 Port PoE Switch
Mikrotik CCS610-8P 8 Port PoE Switch
UniFi U6 Mesh WiFi AP
UniFi U7 Outdoor WiFi 7 AP
CyberPower 1500 Networked On Line Battery Backup for Flypack Systems
*Full equipment list and specifications are subject to change at any time without notice*
